SpeedyBee BLS 35A Mini V2 3-6S BLHeli_S 4-in-1 ESC – Compact 20x20mm 4-in-1 ESC for FPV Drones
SpeedyBee BLS 35A Mini V2 3-6S BLHeli_S 4-in-1 ESC – Compact 20x20mm 4-in-1 ESC for FPV Drones
Regular price
$31.99 USD
Regular price
Sale price
$31.99 USD
Unit price
/
per
Shipping calculated at checkout.
Couldn't load pickup availability
This 35A 4-In-1 ESC features a built-in TVS protective diode, and Japanese made TDK SMT capacitors, and even comes with a low ESR 35v 470uF capacitor.
Powerful Real 35A 4-in-1 ESC!
6-layer 2oz PCB plus optimized circuit design equals stable and strong current output. The four-channel continuous 140A output can reach 30 seconds*.
The use of Japanese TDK filtering SMT capacitors and the onboard TVS protective diode, further enhances your flight experience, providing a seamless and reliable performance. The stack underwent rigorous pressure testing with various 5-inch freestyle and racing drones, confirming its powerful capability to effortlessly drive any 2-4 inch and lightweight 5-inch drones.
TVS Protective Diode + 470uF Low-ESR Capacitor = Upgraded ESC Protection
The ESC is built with TVS protective diode to absorb the voltage spike when you plug in the battery, or during crashes that block your props. We also provide a Rubycon 470uF Low-ESR capacitor, ensuring clean data from the gyro to the FC.
Specifications:
SpeedyBee 35A BLHeli_S Mini V2 4-in-1 ESC
- Firmware BLHeli_S J-H-40
- Continuous Current 35A * 4
- Burst Current 45A(5seconds)
- ESC Protocol DSHOT300/600
- Power Input 3-6S LiPo
- Power Output VBAT(Battery voltage, used to power the flight controller)
- Current Sensor Support (Scale=250 Offset=-500)
- Mounting 20 x 20mm ∅3.5mm hole size,compatible with M2 and M3 screws/Silicone grommets.
- Dimension 35 * 35 * 5.5mm
- Weight 7.2g
Manual
