RCINPOWER AOS RC Supernova 3220 Motor (1 pc) Choose Kv
RCINPOWER AOS RC Supernova 3220 Motor (1 pc) Choose Kv
Couldn't load pickup availability
The AOS Supernova 3220 delivers unmatched power and efficiency for high-speed FPV wings. Perfect for 7-10” props on 6S-8S voltage, it outperforms all other 3220 motors in thrust and response. Engineered through 22,000+ simulations and crafted by RCinPower, it meets the demands of serious pilots. Experience limitless performance with the AOS Supernova 3220.
Features
- High-Speed Wing Optimization
- Customizable Throttle Control
- Unmatched Performance
- Precision Manufacturing
- Versatile Performance
- Cutting-Edge Design
- Proven Excellence
Specifications
700KV
- Motor Dimensions: 39.4mm*36.25mm
- Max. Efficiency Current: (5-12A)>86%
- Max Continuous Power (15S): 2214
- Idle Current (10)@10V (A): 1.8
- No. of Cells (Lipo): 6-8S
- Configuration: 12N14P
- Stator Length: 20mm
- Stator Diameter: 32
- Max Current: 69.2A
- Weight: 170g
- KV: 700
925KV
- Motor Dimensions: 39.4mm*36.25mm
- Max. Efficiency Current: (5-12A)>86%
- Max Continuous Power (15S): 1939
- Idle Current (10)@10V (A): 2.1
- No. of Cells (Lipo): 5-6S
- Configuration: 12N14P
- Stator Length: 20mm
- Max Current: 80.8A
- Stator Diameter: 5
- Weight: 170g
- KV: 925
Includes
- 1x AOS RC Supernova 3220 Motor (Choose Your KV)
- 1x Hardware Kit
Features:
Up to 14% More Thrust
For dynamic 10" Cinelifters pilots need powerful motors capable of delivering peak thrust when you need it most. The AOS Supernova 3220 delivers up to 14% more thrust than other 3220 motors at the same KV thanks to it's optimized magnetic design and is the most powerful motor in it's class. This significantly improves control and thrust to weight ratio.
Up to 23% Faster Response
The faster a motor can respond and change the RPM of the prop the faster it can change thrust. This is vital for stabilising larger drones to provide a smoother and more locked-in flight experience. The increased torque of the Supernova 3220 provides up to a 23% improvement in reposniveness over typical 3220 motors and is the most responsive motor in it's class.
5% Higher Efficiency
Whether you're flying long range or looking to extend flight time efficiency is vital. The AOS 3220 offers a huge uplift in electrical efficiency over previous 3220 motors. It delivers above 80% efficiency over a wide range of throttle settings.
